QJZ Bearings

5309 - Angular Contact Ball Bearing, 1.772" Bore (ID)

5309 - Angular Contact Ball Bearing, 1.772" Bore (ID)

$19.99 USD
$19.99 USD
Sale Ausverkauft
Seal Type

200 auf Lager

Premium Angular Contact Ball Bearing Design

The 5000 series angular contact ball bearings are double-row bearings designed to support combined radial and axial loads. Their precision construction provides reliable performance, high load capacity, and smooth operation in a wide range of industrial and mechanical applications.

Part Number 5309
Inner Diameter (ID) 1.772 in | 45 mm
Outer Diameter (OD) 3.937 in | 100 mm
Width 1.563 in | 39.688 mm

Cross Reference (Interchangeable Numbers)

3309.2RS, 3309-2Z, 3309B, 3309B-2RSTNG, 3309B-2RSTNH, 3309B-2ZR, 3309B.2RSR, 3309B.2RSR.TNH, 3309B.2RSR.TNG, 3309B.2RSR.TVH, 3309B.2Z, 3309ZZ, 5309-2NSE, 5309-2RSR, 5309-2Z, 5309A2RS, 5309A2Z, 5309BLLU, 5309CFF, 5309CZZ, 5309-CFF, 5309DU, 5309E2RS, 5309E2Z, 5309EE, 5309FF, 5309LB, 5309LU, 5309MFF, 5309MZZ, 5309PP, 5309SS, 5309VV, 55609



Applications

  • Electric motors
  • Pumps and compressors
  • Gearboxes and transmissions
  • Machine tool spindles
  • General industrial machinery
