QJZ Bearings
5306 - Angular Contact Ball Bearing, 1.181" Bore (ID)
5306 - Angular Contact Ball Bearing, 1.181" Bore (ID)
797 auf Lager
Verfügbarkeit für Abholungen konnte nicht geladen werden
Premium Angular Contact Ball Bearing Design
The 5000 series angular contact ball bearings are double-row bearings designed to support combined radial and axial loads. Their precision construction provides reliable performance, high load capacity, and smooth operation in a wide range of industrial and mechanical applications.
| Part Number | 5306 |
|---|---|
| Inner Diameter (ID) | 1.181 in | 30 mm |
| Outer Diameter (OD) | 2.835 in | 72 mm |
| Width | 1.189 in | 30.2 mm |
Cross Reference (Interchangeable Numbers)
3206A.2RS1, 3306.2Z, 3306A-2ZTN9, 3306A-2ZTN9MT33, 3306ATN9, 3306B, 3306B-2ZTNG, 3306B-2ZTNH, 3306B.2RSR, 3306B.2Z, 3306B.2ZR.TNH, 3306B.2ZR.TNG, 3306B.2ZR.TVH, 3306B-2ZR, 3306B.TNH, 3306B.TNG, 3306B.TVH, 3306, 3306J, 5306-2NSE, 5306-2NSL, 5306-2RSR, 5306-2Z, 5306-2Z3306ZZ, 5306A, 5306A2RS, 5306A2Z, 5306A-2Z1, 5306A.2RSJ1, 5306AZZ, 5306B-2Z, 5306C, 5306CFF, 5306CZZ, 5306DDU, 5306DU, 5306E, 5306E2Z, 5306FF, 5306KDD, 5306LB, 5306LLB, 5306LLU, 5306LU, 5306M, 5306MFF, 5306PP, 5306RS, 5306SS, 5306VV, 5306W, 5306Z, 5306-ZZ, B5306-2RSR, B5306.2ZR, 55606, 11X-330, M-224, 3056306, 30BE33, 7BBNON30, I-130091, I-132279, I-92905B, X-556065306 ZZ
Applications
- Electric motors
- Pumps and compressors
- Gearboxes and transmissions
- Machine tool spindles
- General industrial machinery
