QJZ Bearings
5304 - Angular Contact Ball Bearing, 0.787" Bore (ID)
5304 - Angular Contact Ball Bearing, 0.787" Bore (ID)
500 auf Lager
Verfügbarkeit für Abholungen konnte nicht geladen werden
Premium Angular Contact Ball Bearing Design
The 5000 series angular contact ball bearings are double-row bearings designed to support combined radial and axial loads. Their precision construction provides reliable performance, high load capacity, and smooth operation in a wide range of industrial and mechanical applications.
| Part Number | 5304 |
|---|---|
| Inner Diameter (ID) | 0.787 in | 20 mm |
| Outer Diameter (OD) | 2.047 in | 52 mm |
| Width | 0.874 in | 22.2 mm |
Cross Reference (Interchangeable Numbers)
3204A.2RS1, 3304.2Z, 3304A-2ZTN9, 3304B-2ZTNG, 3304B-2ZTNH, 3304B.2RSR, 3304B.2Z, 3304B.2ZR.TNH, 3304B.2ZR.TNG, 3304B.2ZR.TVH, 3304B-2ZR, 3304ZZ, 5304-2NSE, 5304-2NSL, 5304-2RSR, 5304-2RSR5304A2RS, 5304-2ZJ1, 5304A2RS, 5304A2Z, 5304A.2RSJ1, 5304BZZ, 5304CFF, 5304CZZ, 5304DDU, 5304DU, 5304E2Z, 5304FF, 5304KDD3304.2Z, 5304LB, 5304LLB, 5304LLU, 5304LU, 5304MFF, 5304PP, 5304RS, 5304VV, 5304ZZ, 5304 Z, 5304-CFF, B5304-2RSR, 3304-2Z
Applications
- Electric motors
- Pumps and compressors
- Gearboxes and transmissions
- Machine tool spindles
- General industrial machinery
